ADDER INFINITY 1102T Single-Head Digital Video/Audio Over IP Network KVM Transmitter

The ADDERLink INFINITY 1102 is a high-performance IP KVM extender that allows for the relocation of critical computing hardware into a secure and temperature-controlled environment, away from the user workstation. This device ensures a pixel-perfect desktop experience, maintaining the integrity of the digital video and audio signals transmitted over a standard IP network. With its spatially-lossless encoding system, the ADDERLink INFINITY 1102 delivers color-accurate video without artifacts, making it ideal for professional environments where visual fidelity is paramount.

Designed for flexibility and scalability, the ADDERLink INFINITY 1102 can be configured as a simple extender or as part of a self-managed distributed KVM switch. It supports USB 2.0 devices, including graphics tablets and mass storage devices, while also providing options for network redundancy and unlimited extension distances. This makes it a versatile solution for various applications, from broadcasting to control rooms, where reliable and high-quality video and audio transmission is essential.

Key Features:

  • Maximum Resolution: 2560 x 1600
  • Frame Rate: 60 fps
  • USB B: 1x 2.0 True Emulation, High Speed
  • USB A: 1x 2.0 True Emulation
  • Full Size DisplayPort: 1x
  • 8p8c (RJ45): 1x
  • SFP: 1x
  • Serial Standard: RS232
  • Maximum Baud Rate: 115,200
  • Bandwidth: 1GbE
  • Operating Temperature: 0 - 40 °C / 32 - 104 °F
  • Storage Temperature: 0 - 40 °C / 32 - 104 °F
  • Operating Humidity: 5% - 90% (non-condensing)
  • Altitude: 2000m / 6561.68ft
  • Mean Time Between Failure (MTBF): 476,000 h
  • Power Supply: External Power Supply Unit
  • Power Consumption: 12V 3-pin
  • Construction Material: Robust metal construction
  • Dimensions: 136mm x 39mm x 150mm
  • Weight: 0.8kg / 1.76lb

Technical Specifications:

Category1: KVM Extender
Category2: IP Technology
Maximum Resolution: 2560 x 1600
Frame Rate: 60 fps
USB Support: 2.0 True Emulation
Operating Temperature: 0 - 40 °C / 32 - 104 °F
Weight: 0.8kg / 1.76lb
MTBF: 476,000 h

Package Contents:

  • 1x ALIF1102 Transmitter
  • 1x PSU-IEC-12VDC-1.5A: Mains power supply
  • 1x IEC PSU cable of country code
  • 1x VSCD18: 2m/6.5ft DisplayPort cable
  • 1x VSC24: 2m/6.5ft USB cable
  • 1x VSC22: 2m/6.5ft Audio cable
"
